Flame Proof Pressure Transmitter Exd Grade
Flame Proof Pressure Transmitter for explosion-proof mark Ex d IIC T6 Gb.
Its explosion-proof “d” explosion-proof form can be used in hazardous area zones 1 and 2, but cannot be used in hazardous area zone 0.
Equipment category IIC means IIC that can be used not only for gas and steam classification. It can also be used for IIB and IIA;
The temperature group T6 of its electrical equipment means that it can be used not only for T6, but also for T5, T4, T3, T2 and T1;
Corresponding equipment protection level (EPL) Gb – indicates a high level of protection. It can provide appropriate high protection for hazardous areas Zone 1 and Zone 2. However, it cannot provide appropriate protection for Zone 0, which is a higher level of danger.
Explosion-proof transmitters are suitable for installation in places with explosive gases, vapors, dusts and fibers to protect the safety of operators, instruments and equipment. It is used to continuously measure the differential pressure, pressure, negative pressure, liquid level and flow rate of steam, gas, liquid and other media.
When the site contains corrosive gases and ferromagnetic dust, explosion-proof transmitters should also be selected.
Flameproof Pressure Transmitter Exd | Sino-Insts
Flameproof Pressure Transmitter 4-20ma, diffused silicon, measures water pressure, hydraulic pressure, oil pressure, and air pressure.
Product Brand: Sino-Inst
Product Currency: USD
Product Price: 175
Price Valid Until: 2029-09-09
Product In-Stock: InStock
