Cryogenic Turbine Flow Meter for Low Temperature Fluid

Low Temperature turbine flow meter is suitable for measurement of liquid gas. Measurements are usually performed in low temperature environments and can even be used in -200°C environments.

1. Measurable low-temperature fluids include LNG, liquid nitrogen, liquid oxygen, liquefied ethylene, liquid hydrogen, etc.;
2. The bearings are made of high-quality carbide bearings, which are resistant to abrasion, corrosion and long life.
3. Low temperature turbine flowmeter: -196℃~normal temperature. The sensor structure uses specially customized imported materials and is equipped with a low-temperature resistant amplifier;
4. A variety of installation methods are available: thread, flange, quick installation, direct welding, etc.;
5. Can be used with the flow totalizer to complete remote display;
6. Can be combined with control instruments and control systems to form automatic quantitative conveying and feeding equipment;

Get A Free Quote

Cryogenic Turbine Flow Meter Description

Cryogenic turbine flow meter is an upgrade and development based on the conventional liquid turbine flow meter. Dedicated to flow measurement of cryogenic fluids. The use of cryogenic fluids and liquefied gases such as liquefied natural gas (LNG) has grown significantly. Cryogenic turbine flow meter is an innovative solution for monitoring, metering and measuring cryogenic fluids.

Cryogenic turbine flow meter can measure low-temperature fluids such as LNG, liquid nitrogen, liquid oxygen, liquefied ethylene, liquid hydrogen, etc.

Sino-Inst has many years of experience in cryogenic fluid measurement and control. We have mature technologies in low-temperature medium pressure measurement, temperature measurement, and liquid level measurement.

Low Temperature Turbine Flowmeter Technical Parameters

Nominal diameter:	Common type (2～300) mm;
Medium temperature:	Normal temperature range: -20～100℃
	Sub-high temperature type: -20～130℃, high temperature type: -20～180℃
	Sub-low temperature type: -40℃～normal temperature,
	low temperature type: -196℃～normal temperature
Ambient temperature:	-20～55 ℃;
Accuracy:	±0.5%, ±1%;
Detector signal transmission line system:	three-wire voltage pulse (three-core shielded cable);
Power supply:	External power supply: 24VDC Battery power supply: 3.6V lithium battery (replace the battery about 3 years)
Transmission distance:	The distance between the sensor and the indicator can reach 250 meters;
Output voltage amplitude:	high level ≥ 8V, low level ≤ 0.8V;
Display mode:	on-site LCD display instantaneous flow and accumulated flow;
On-site display power supply with signal output:	Pulse signal: push-pull output Current signal: 4-20mA Voltage output: 0-5V, 0-10V Communication interface: RS485 (MODBUS), HART protocol Alarm signal: relay upper and lower limit alarm or open collector type

Get Solutions for Cryogenic Fluid Measurement

Sino-Inst is a leading manufacturer of high quality cryogenic turbine flow meters. We have experience measuring various cryogenic fluids. Including LNG, liquid nitrogen, liquid oxygen, liquefied ethylene, liquid hydrogen, etc.

Products Categories

Coriolis Mass Flow Meter

Thermal Gas Mass Flow Meter

Differential Pressure Flow Meter

Electromagnetic Flowmeter

Ultrasonic Flow Meter

Vortex Flowmeter

Turbine Flowmeter

Positive Displacement Flow Meters

Compact Pressure Sensor/Transmitter

High Temperature Pressure Transmitter

Cryogenic Pressure Transducer

High Temperature Melt Pressure Transmitter

Explosion-Proof Pressure Transmitter

Differential Pressure Transmitter

Hydrostatic Level Transmitter

Ultrasonic Level Transmitter

Radar Level Meter

Paperless Recorder

Get A Free Quote

Application: Measurement of cryogenic liquid turbine flowmeter in Cold Chain Transportation

The medium in cold chain transportation can be measured with a cryogenic liquid turbine flowmeter.

The cryogenic liquid turbine flow meter is a precision instrument that can accurately measure the flow rate of liquid in a pipeline. Due to the high accuracy, high reliability and ease of use of the cryogenic liquid turbine flowmeter, the cryogenic liquid turbine flowmeter can also help logistics companies save costs, improve efficiency and reduce waste. Therefore, cryogenic liquid turbine flowmeters are widely used in cold chain transportation.

Cryogenic liquid turbine flow meters are suitable for measuring liquid gases, usually in low-temperature environments, and can even be used in environments of minus 200 degrees, such as during the transportation of food, medicine, and chemicals. Its main principle is to detect the speed and amount of fluid by rotating a turbine. As the liquid passes through the pipe, the rotating turbine is acted upon by the liquid, producing a pulse signal. These signals are captured by sensors and flow data is calculated.

With the continuous development of science and technology, cryogenic liquid turbine flowmeters will surely be more widely used in the future and make a huge contribution to the development of the logistics industry.

Cryogenic Turbine Flow Meter for Low Temperature Fluid Detail Display

More Detail

What flowmeter is used for cryogenic?

The applicable measurement temperature limit for most flow meters is around -40°C. When the temperature is lower, we need to choose some flow meters specifically suitable for low temperature measurement.

Our Sino-Inst cryogenic flowmeter types include: gear flowmeter, Coriolis mass flowmeter, and cryogenic turbine flowmeter.

What is a chilled water flow meter?

Chilled water flow meter is capable of measuring the flow rate of low-temperature water. Common chilled water flow meters include electromagnetic flow meter, turbine flow meter and ultrasonic flow meter.

Chilled water flow meters can be used on condensing systems, chillers or HVAC. In chilled water systems, monitoring of flow and energy is necessary. Sino-Inst manufactures and supplies a range of Chilled water flow meters, as well as heat meters.
